Features:
1. Ingenious machine body, portable: Ultra-small size design, easy to carry and save space.
2. Light weight, easy to move: Optimized weight ratio, easy handling, no burden.
3. Multi-point refrigeration, excellent quality: Integrated all-round refrigeration system, quickly reach sectioning temperature.
4. Compact cryochamber, easy operation: Small chamber design, maximized space utilization, convenient to use.
5. Intelligent memory, simplify the process: The specimen head is equipped with intelligent location memory function, one click to return to the preset position.
6. Anti-collision protection, safety upgrade: integrated automatic anti-collision knife mechanism to protect the safety of equipment.
7. Precise specimen feeding, stable sectioning: High-precision specimen feeding system to achieve micronized accurate control.
8. Color touch, easy to operate: High-definition color LCD touch screen, intuitive display of functions and parameters.
9. Induction lighting, clear details: Intelligent induction lighting, adjustable brightness at will, which helps accurate operation.

Main Technical Data:
1.Sectioning thickness range: 0.5-100μm，Default: 6µm
2.Section Thickness Setting: 0.5-5 µm，Step 0.5µm
                          5-20 µm，Step 1µm
                          20-60µm，Step 5µm
                          60～100µm，Step 10µm
3.Trim Thickness range: 1-600μm，Default：20µm
4.Trim Thickness Setting: 1-10μm，Default：1µm
                        10-20μm，Step：2µm
                        20-50µm，Step 5µm
                        50-100µm，Step 10µm
                        100-600µm，Step 50µm
5.Feeding Drive Mode: Driven by stepper a motor, ensuring precise and stable sample drive.
6.Specimen Head Memory: Memorize the specimen head feeding position, after replacing with a new tissue specimen, it can directly reach to the remembered position with one click.
7.Specimen Head Retraction: Support retraction within the range of 0-250 µm (0µm is off). The default value is 20µm.
8.Specimen Head Coarse Feeding Speed: 900-2000µm/s，Default：1800µm/s
9.Specimen Head Fine Feeding Speed: 100-900µm/s，Default：300µm/s
10.Horizontal Stroke of Specimen Head: 25±1mm
11.Vertical Stroke of Specimen Head: 60±1mm
12.Specimen Positioning: Specimen holder 360°rotation, zero position indicator
13.Specimen Head Return: Press the “Fast Backward” key to quickly return, and press the “Fast Backward” key again to stop the return, the return speed is 2000µm/s
14.Handwheel Lock: Locked at 6 o’clock, locked at 12 o’clock
15.Blade Holder: Compatible with high profile and low profile blade, horizontal movement 48mm, Angle adjustment: 0 -15°

Refrigeration Parameters:
1.Refrigeration Positions: Multi-point refrigeration, supporting 4 positions refrigeration including cryo chamber, specimen head, knife holder, and freezing shelves
2.Temperature Display: Temperatures of cryo chamber, specimen head, knife holder, and freezing shelves
3.Temperature Setting: Specimen head: -5℃～-50℃±5℃，default: -15℃
4. Cooling Method: Single compressor cooling.
5.Number of Freezing Stations: 3

Auxiliary Parameters:
1. Disinfection Function: UV disinfection, manual disinfection, selectable 30min, 60min, and 180min.
2. Illumination: Automatic window illumination with sensor, supports manual on/off, adjustable brightness.
3. Data Accumulation: Accumulates cutting/trimming thickness and number of cuts, resettable.
4. Automatic Standby: Standby time range 1-60min, default 5min.
5. Anti-collision Blade Function: Supports anti-collision blade position marking; can be remarked after moving the blade holder.
6. Audible Alarm: Audible alert when specimen head arrives at front and rear positions.
7. Screen: 5-inch color LCD touchscreen; all functions and parameters can be operated and set via the touchscreen for convenient operation.
8. Window: Single-layer non-heated glass.
9. Cold Box Volume: 14.5L (Length 335mm, Width 180mm, Depth 240mm)
10. Button Panel: Physical button panel on the left side of the device, supporting common functions such as fast forward, fast rewind, slow forward, slow rewind, thickness adjustment, and trimming/slicing conversion.
11. Power: 370W
12. Dimension: Width * Depth * Height: 590mm (Handle Included) * 715mm * 445mm
13. Net Weight: 70kg

Accessory Specifications
1. Blade guard: High-visibility red finish.
2. Blade ejector: Integrated into the blade guard; blade ejection via push rod.
3. Specimen holder: Adopts flat structure. Larger contact area with cooling stage and specimen head for improved sample freezing efficiency. Standard equipped with φ35mm size only.

Standard Configuration List
1.    Cryostat   1 unit
2.    Power cord (2m)   1 pc
3.    Fuse (10A)   4 pcs
4.    Sample tray (with rubber ring 32*28*3)   5 pcs
5.    Handwheel (with plug cover, including positioning pin)   1 pc
6    Fixed heat absorber (cold hammer)   1 pc
7.    Wheel mounting screw (M5*20)       1 pc
8.    Handle   1 pc
9.    Waste liquid tray   1 pc
10.    E-type knife holder   1 pc
11.    Waste box   1 pc
12.    Writing brush       1 pc
13.    Tweezers   1 pc
14.    Embedding medium (OCT)       1 pc
15.    Blade   1 pc
16.    Small screwdriver (3*50mm)   1 pc
17.    Hexagon wrench   1 pc
18.    Instruction manual   1 pc

 Package Info:
Each instrument packed Wooden Case
Packing Size: 887*830*645mm
Gross Weight: 108kg


​​​​​​​
